37KW Variable-Frequency Electric Wire Saw Machine for Reinforced Concrete Cutting
CAHARD 37KW variable-frequency electric wire saw machine is designed for reinforced concrete cutting, structural modification and demolition projects that require a higher-power wire sawing configuration.
The machine combines a 37KW electric main drive with a maximum diamond wire linear speed of 40 m/s and a maximum 500 mm drive wheel. Wireless remote control allows the operator to manage the machine from a suitable working position during cutting.
Higher-Power Cutting Performance
The 37KW main drive provides a higher-power configuration for reinforced concrete cutting projects with greater cutting workload.
The machine supports a maximum diamond wire linear speed of 40 m/s for reinforced concrete cutting applications.
The reference average cutting efficiency is 5 m²/h. Actual output depends on concrete strength, reinforcement level, cutting size, diamond wire specification and site conditions.
Main-drive speed can be adjusted according to actual cutting requirements, allowing the operator to adapt the machine to different reinforced concrete conditions and diamond wire configurations.
Typical Applications & Project Fit
- Reinforced concrete wall cutting
- Concrete beam and column cutting
- Foundation and structural concrete cutting
- Structural modification projects
- Building renovation and structural demolition
When to Consider the 37KW Model
Consider the 37KW model when the project calls for a higher power level, higher maximum wire speed or higher reference cutting efficiency than the 22KW configuration. Final machine suitability depends on concrete strength, reinforcement level, structure dimensions, cutting workload, diamond wire specification and actual site conditions.
Technical Specifications
| Main Drive Power | 37 KW |
| Power Source | Electric |
| Spindle Output Speed | 975 rpm |
| Maximum Wire Linear Speed | 40 m/s |
| Maximum Drive Wheel Size | 500 mm |
| Voltage / Frequency | 380 V / 50 Hz |
| Power Cable Requirement | 16 mm² three-phase five-core cable |
| Control Method | Wireless remote control |
| Speed Control |
Main motor: adjustable speed Secondary motor: forward / reverse movement with stepless speed adjustment |
| Average Cutting Efficiency (Reference) | 5 m²/h |
| Machine Weight | 480 kg |
| Machine Dimensions | L2300 × W900 × H1000 mm |
Standard Accessories
| Standard Accessory | Quantity |
|---|---|
| Wireless Remote Control | 1 pc |
| YQK240 Hydraulic Pliers | 1 pc |
| 24-inch Cutter | 1 pc |
| Explosion-Proof Plug | 1 pc |
Tell Us About Your Cutting Project
If you are evaluating a higher-power wire saw for reinforced concrete cutting or demolition work, send us your project conditions. CAHARD can help you determine whether the 37KW configuration is suitable for your cutting requirements and workload.
Please provide the following information when possible:
- Material to be cut
- Concrete strength, if known
- Structure dimensions or concrete thickness
- Reinforcement level
- Expected cutting volume or project workload
- Available voltage and frequency
- Destination country / port
- Required quantity
If diamond wire is also required, please provide the cutting material and reinforcement details so we can recommend a suitable wire configuration.
Send us your project conditions and cutting workload to receive machine recommendations, product details and a quotation.
